                                                                                                                                              Workstation/
                                                                                                   Macintosh                                  Portrait(6)
                                                                     High-Resolution               Display      Macintosh    Display          630-????
                                                     Macintosh II    Video Display     Mac Dsply   Card 670     Display      Card     Mac II     |     2-Page
                        Apple NuBus Video Cards--->  Video Card(1)  .....Card(1).....   4•8 (2)    8•24         8•24GC       24AC     Mono       |     Mono(6)
                                                      630-0153      630-4222 630-4230   630-0400   820-0600-A   670-0310              630-4385   |     6??-????
     Model #   Apple Monitors            resolution  4 bit   8 bit    4 bit  8 bit      8 bit      24 bit       24 bit       24 bit   1 bit    2 bit   2 bit
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ---
12"  M1296 Macintosh 12-in RGB Display      512x384    -       -         -      -       256        16.7M        16.7M*         -       -         -      -
12"  M0400 High Res Monochrome Monitor      640x480    16     256*      16     256*     256*       16.7M*       16.7M*       16.7M     2*        -      -
12"  M1050 Macintosh 12-in Monochrome Dsply 640x480    16     256       16     256      256        16.7M*       16.7M*       16.7M     2         -      -
13"T M0401 AppleColor High-Res RGB     (A)  640x480    16     256*      16     256      256*       16.7M*       16.7M*       16.7M     2*        -      -
 "   M1297   "          "       "      (B)   "
14"T M1212 Macintosh Color Display          640x480    16     256       16     256      256        16.7M        16.7M        16.7M               -      -
14"T M2001 Audio-Vision 14 Display          640x480    16     256       16     256      256        16.7M        16.7M        16.7M               -      -
14"  M1595LL/A Basic Color Monitor (vga)    640x480    -       -        16              256          -            -            -                 -      -
14"  M1787 Apple Color Plus 14-in Dsply (A) 640x480    -       -        16     256      256        16.7M        16.7M        16.7M               -      -
 "   M2346   "     "    "     "     "   (B)  "
14"  M9101 Apple Performa Display           640x480                     16     256      256        16.7M        16.7M        16.7M
14"  M9102 Apple Performa Plus Display      640x480                     16     256      256        16.7M        16.7M        16.7M
15"  M0404 Macintosh Portrait Display   (A) 640x870    -       -         -      -        16         256          256?        ?????               4      -
 "   M1030   "         "        "       (B)  "
16"T M1298 Macintosh 16-in Color Display    832x624    -       -         -      -        16? (4)    256* (5)    65.5K* (5)   16.7M               -      -
21"  M0402 Two-Page Monochrome Monitor  (A)1152x870    -       -*        -      -*       16*        256*         256*         256                -      4
 "   M1025    "         "       "       (B)  "
21"  M3502 Macintosh 21-in Color Display   1152x870    -       -         -      -        16*        256*         256*        16.7M
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ---
14"  M4222 Multiple Scan 14 Display         640x480    -       -        16     256      256        16.7M        16.7M        16.7M
                                            800x600    -       -         -      -        -           -            -            -
                                            832x624    -       -         -      -        16? (3,4)  256 (3,5)   65.5K (3,5)  16.7M

15"  M2943 Multiple Scan 15 Display         640x480    -       -        16     256      256        16.7M        16.7M        16.7M
                                            800x600    -       -         -      -        -           -            -            -
                                            832x624    -       -         -      -        16? (3,4)  256 (3,5)   65.5K (3,5)  16.7M
                                           1024x768    -       -         -      -        -           -            -            -

17"T M2494 Multiple Scan 17 Display         640x480    -       -        16     256      256        16.7M        16.7M        16.7M
17"  M4436 Multiple Scan 1705 Display       800x600    -       -         -      -        -           -            -            -
                                            832x624    -       -         -      -        16? (3,4)  256 (3,5)   65.5K (3,5)  16.7M
                                           1024x768    -       -         -      -        -           -            -          16.7M

17"T M2935 AppleVision 1710 Display         640x480    -       -        16     256      256        16.7M        16.7M        16.7M
17"T M2942 AppleVision 1710 AV Display      800x600    -       -         -      -        -           -            -            -
                                            832x624    -       -         -      -        16? (3,4)  256 (3,5)   65.5K (3,5)  16.7M
                                           1024x768    -       -         -      -        -           -            -          16.7M
                                           1152x870    -       -         -      -       16?         256?         256?          -
                                          1280x1024    -       -         -      -         -           -           -            -

20"T M1823 Multiple Scan 20 Display         640x480    -       -        16     256      256        16.7M        16.7M        16.7M
                                            800x600    -       -         -      -        -           -            -            -
                                            832x624    -       -         -      -        16? (3,4)  256 (3,5)   65.5K (3,5)  16.7M
                                           1024x768    -       -         -      -        -           -            -          16.7M
                                           1152x870    -       -         -      -        16 (3)     256?         256?        16.7M
                                          1280x1024    -       -         -      -         -           -            -            -
(1) Can be upgraded with eight Mac II Video Expansion RAM chips for 256 grays/colors.
(2) The 4•8 can be upgraded to a 8•24 by adding two 256k VRAM SIMMs.
(3) Requires Display adaptor to use Multiple Scan Displays at this resolution.
(4) Available with rev. B ROM.
(5) Available with rev. B card.
(6) Can be upgraded with eight Mac II Video Expansion RAM chips for 16 grays.
(*) verified by test
Apple Tech Info links
Macintosh: Monitor and Video Chart (1 of 4)   (2 of 4)   (3 of 4)   (4 of 4)
Apple Displays: Model Numbers
Apple Displays: Frequently Asked Questions
Macintosh 12-Inch RGB Display: Compatible Systems
Apple High-Resolution Monochrome Monitor: Specs Created: 3/6/87 Modified: 9/13/93 (DA-15 style connector)
Macintosh 12-Inch Monochrome Display: Description Created: 5/27/92 Modified: 6/7/94 (attached video cable)
Macintosh II: Monochrome Video Card
Macintosh II High-Resolution Video Card: New Features
Macintosh II: Old and New Video Card Part Numbers, Etc.
Macintosh IIci: Internal Video Circuitry Versus Video Card
Macintosh IIci Video: Supported Resolutions and Scan Rates
AV Series, Apple Nubus Video Cards: Compatibility
Macintosh Display Cards Overview (1 of 3)  (2 of 3)  (3 of 3)
Monitor Cables: Pinout Information
Sense Lines
Color Monitor Connections Macintosh II Video Card, Macintosh LC & IIci built-in video to third-party monitors.
Scan Rates for Monitors
Macintosh VRAM Chart
PORTRAIT & TWO PAGE
Macintosh II Portrait Display Card: Specs
Macintosh IIci: Two-Page Monitors Need NuBus Video Card
4•8
Macintosh Display Card 4•8: Color Problems
Display Card 4•8 and 8•24 Specifications
8•24GC
 Software
Control Panel v1.1 & v7.0.1
Cache Control 030
 Docs
Display Card 8•24 GC: Specifications
Macintosh Display Cards 8•24 & 8•24 GC: Rev A/B Differences
Display Card 8•24 & 8•24 GC: Identifying Rev & Upgrade ROM
System 7.5: 8•24GC Card Compatibility
Display Card 8•24 GC: Using With Different Monitors
Worth-of-8-24-gc-card I
Worth-of-8-24-gc-card II
Macintosh Display Card 8•24GC: The Naked Truth
24AC
  -Date-  -Article#-  Subject
07/27/94 - 15049 - Macintosh Display Card 24AC: Compatibility With Power Macintosh
12/21/94 - 14837 - Macintosh Display Card 24AC: Technical Specifications
02/22/95 - 17245 - Display Card 24AC: Power Macintosh Can Use Acceleration
06/28/95 - 13987 - Display Card 24AC: Description
07/23/98 - 20599 - Mac Display Card 24AC: ROM V1.0 Not Compatible w/7.5.3
24AC video card datasheet (html)
24AC video card datasheet (pdf)

VIDEO DRIVERS more drivers
Link to Micron XCEED software.

SuperMac
SuperMac SuperVideo 2.7.5 control panel.
SuperMac SuperVideo 3.1
SuperMac VideoSpigot SpigotVDIG 1.0    extension.
SuperMac VideoSpigot SpigotVDIG 1.5B18 extension.
SuperMac VideoSpigot DigitalFilm 1.5 application.
SuperMac VideoSpigot ScreenPlay 1.2.2 application.

Radius
RadiusWare for old Macs (Displays and accelerators)
RadiusWare Pivot v3.2.1 Software Dynamic Desktop 3.3, Soft Pivot 3.2.1, Soft Pivot Driver 3.2.1
RadiusWare NuBus GS Installer Dynamic Desktop 3.1.1, PowerSaver 1.1
RadiusWare NuBus v3.2.5 Dynamic Desktop 3.2.5, QuickColor 3.2.5, Soft PrecicsionColor 3.1.1, PowerSaver 1.2.1
RadiusWare 3.3 Dynamic Desktop 3.3, QuickColor 3.3, •RADIUS DSP 2.2, RadiusWare 2.3.2, MrFlash 1.2.3
Thunder IV Software Dynamic Desktop 3.3, QuickColor 3.3, •RADIUS DSP 2.2, Radius PhotoEngine Plug-in 1.2
Thunder IV 1.2.3 Update MrFlash 1.2.3

Thunder 24 Manual
RadiusTV installer
Radius PhotoBooster
Radius Studio Player 2.6.2

E-Machines
E-Machines Control Panel 3.5.6 For Futura II LX/DSP, Futura II SX/DSP, Futura II LX, and Futura II SX video cards.

RasterOps
RasterOps Graphics Install
Drivers
Drivers
Video Display Card Compatibility Matrix

Truevision NuVista+ ftp site
Software and Manual
                                                640x480     800x600                                        1280x1024   1600x1200
                                                   |           |                                               |           |
                                          512x384  |  640x870  |  832x624  ___1024x768___   _____1152x____     | 1360x1024 |
                                     Part                                  60Hz 65Hz 75Hz   870   882   910
NUBUS & PDS VIDEO CARDS               No.    A     B     D     E     F     G     H     I     J     K     L     M     N     O
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Radius
Radius Full Page Display         630-0009
Radius Full Page Display (SE)        0034
Radius Two Page Display TPDII        0039 630-0041-D
Radius Two Page Display (SE30)       0187 . . . . . . . . . . . . . . . . . . . . . . . . . . . .  1
Radius GS/C GS/C-M . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Radius DirectColor 8/16/24 . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  Y
Radius DirectColor GX . . . . . . .  . . . . . . . . .  24
Radius Color Pivot               630-0070
Radius Color Pivot For LC            0407          8     8
Radius Pivot Card For IIsi           0409          8     8
Radius Pivot Card SE30               0410          8     8           8
Radius PrecisionColor 8-Xj           0369    8     8           8     8     8     8     8     8     8
Radius PrecisionColor 8-24X (24 b)                24          24    24    24          24    24
Radius PrecisionColor 24X            0354
Radius PrecisionColor 24XK           0391         24          24    24    24          24
Radius PrecisionColor 24XP           0380                                          -->24
Radius PrecisionColor Pro 24X        0429                                 24
Radius PrecisionColor Pro 24XK       0430   24    24                24    24                24
Radius PrecisionColor Pro 24XP       0431                           24
Radius PrecisionColor Pro 24ac                    24          24    24                24    24
Radius Thunder 24 Gt                 0491         24                24                24    24     8                 8     8
Radius Photo Engine Upgrade (0491)   0482
Radius Thunder Iv Gx 1152            0485         24                24                24    24?   24                 8     8
Radius Thunder Iv Gx 1360            0446         24                24                24    24    24                24     8
Radius Thunder Iv Gx 1600            0513         24                24                24    24    24                24    24

SuperMac
SuperMac ColorCard. . . . . . . .  . . . . . . . . 8
SuperMac ColorCard SE/30
SuperMac ColorCard/24               G0630
SuperMac Spectrum . . . . . . . .  . . . . . . . . .  . . . . . . . . . .  8
Supermac Spectrum/8 LC              G1350
Supermac Spectrum/8 si              G1340
Supermac Spectrum/8 Series II SE/30
Supermac Spectrum/8 PDQ             G0430
SuperMac Spectrum/8 Series II     STD9412
Supermac Spectrum/8 Series III      G0231          8                 8                 8
Supermac Spectrum/8 Series IV
Supermac Spectrum/8€24              G1830
Supermac Spectrum/8€24 PDQ si
Supermac Spectrum/8€24 PDQ v1.0     G0930   24    24     24         16     8           8     8     8
                           v1.7.2   G0930   24    24     24         16     8           8     8     8     8
Supermac Spectrum/24 Series III     G0330
Supermac Spectrum/24 Series IV      G2230   24    24     24         24    24          24
Supermac Spectrum/24 Series V       G3930   24    24                24                24
Supermac Spectrum/24 PDQ
SuperMac Spectrum/24 PDQ Plus v1.60 G1430   24    24     24         24    24          24    24    24    24
Supermac Thunder Light              G2130
Supermac Thunder/24                 G1130         24                24                24    24
Supermac Thunder II Gx 1152         G3730         24                24                24    24
Supermac Spectrum Power 1152        G3430   24    24                24                24    24    24
Supermac Thunder II 1360            G2330
Supermac Thunder II Gx 1360 v3.0.0  G3130   24    24     24         24    24?         24    24    24    24          24
Supermac Thunder II Gx 1600         G3230         24                24                24    24                      24    24
Supermac Thunder II GX Upgrade      G3830
Supermac Video Spigot              DV1030
Supermac Video Spigot & Sound      DV1131
Supermac Spigot Power AV           DV1630
Supermac  Superview                PB0161

E-Machines
Spec/24 IV
DoubleColorSX                                      8                 8                 4
Colorlink SX/t                                    24                 8                 8
Futura SX                                         24                24                 8
Futura MX                         1424-XL         24                24                24
Futura II LX                      EMG023L
Futura II SX                      EMG013S
Power Link Presenter              5008PLP
Ultra LX Long Card                EMG043L
Simply TV                         EMG0550
Apple Mac Video               029-00154-00
   Card- The Big Picture II

RasterOps
Movie Pak                            2543
Movie Pak II                         2676
Video Time                           2562
Specs for other RasterOps (gif)

Micro Conversions
                             2124NB-II            24    24          24                24    24

Micron Xceed specs

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
NUBUS & PDS VIDEO CARDS               No.    A     B     D     E     F     G     H     I     J     K     L     M     N     O
                                     Part 512x384  |  640x870  |  832x624  60Hz 65Hz 75Hz   870   882   910    | 1360x1024 |
                                                   |           |           ___1024x768___   _____1152x____     |           |
                                                640x480     800x600                                        1280x1024   1620x1200
The following is courtesy of M & M Enterprises' Vancouver field office. E Machines Futura card switch settings: Resolution Refresh Monitors 1 832 x 624 67 hz T16 2 1024 x 808 71 hz T19/TX 3 648 x 480 60 hz VGA 4 1024 x 768 60 hz GDM-1952,1602 5 832 x 624 75 hz T16a-E16 6 1024 x 768 75 hz E16, Supermac 19 7 640 x 480 67 hz E16 8 1024 x 768 75 hz Rasterops 19 C 13"/16" Dual Resolution E16 D 16"/19" Dual Resolution T16II/E16 E 19"/21" Dual Resolution T19II F 16"/21" Dual Resolution T16II Futura SX 1.5 MB VDRAM Futura MX 3 MB VDRAM Futura LX 3 MB VDRAM
This page copyright © 1999-2003 by Gamba. All rights reserved.
